2MBI400NC-12 Double IGBT Module – 400A 1200V

Introduction to 2MBI400NC-12 Double IGBT Module

The 2MBI400NC-12 Double IGBT Module If you’re the type who’s trying to dig into industrial electronics or high-power control systems, you’ve probably crossed paths with the 2MBI400NC-12 Double IGBT Module. But what is it about this one that makes it so crucial? Why does everybody favor it, from motor drives to solar inverters? We’re going to unpack it all — simply, clearly and comprehensively.

What is an IGBT Module?

Basics of IGBT (Insulated Gate Bipolar Transistor)

An IGBT (Insulated Gate Bipolar Transistor) is the equivalent of a hybrid in electronics. It possesses the high input impedance of a MOSFET and the low on-state power loss of a BJT. The result? Quick‐switching, low conduction loss, and good controllability for high power devices.

Role of IGBT Modules in Power Electronics

IGBT modules are employed to step up or switch over electric power in multiple applications. Whether they’re HVAC units or solar inverters, they help keep the lights on by converting and managing energy itself.

Why Use Double IGBT Modules?

There are IGBTs in packages with two IGBTs is two are connected together, to achieve a reduction in size, better performance and simpler wiring (such as, for example, the 2MBI400NC-12).

Buy 2MBI400NC-12 Double IGBT Module – 400A 1200V online

Where can I buy the 2MBI400NC-12Double IGBT Module If you want to purchase the 2MBI400NC-12Double IGBT Module, you can order it here in our online store. The link is given below.

👉 click here

Overview of 2MBI400NC-12

Key Specifications

• Current Rating: 400 Amps
• Voltage Rating: 1200 Volts
• Configuration: Dual IGBT module
• Package: Isolated Baseplate

Electrical Characteristics

It supports:

• Collector-emitter voltage (Vce): 1200V
• Collector current (Ic): 400A continuous
• Gate-emitter voltage (Vge): ±20V max

Thermal and Mechanical Features

• Baseplate: Copper for excellent heat conduction
• Isolation Voltage: 2500V RMS
• Weight: Compact for its class

💡 Core Features of 2MBI400NC-12

High Current Handling (400A)

This module is designed to withstand massive loads, ideal for demanding industrial systems.

High Voltage Capacity (1200V)

1200V capability means it can be used in medium to high voltage systems safely.

Low Saturation Voltage Drop

Lower Vce(sat) means less heat, more efficiency, and longer life.

Fast Switching Performance

Perfect for applications where quick and repeated switching is critical—like VFDs (Variable Frequency Drives).

Applications of 2MBI400NC-12

Industrial Automation

It keeps assembly lines, CNC machines, and industrial robotics in action.

Renewable Energy Systems

Used in solar inverters and wind turbines for converting and managing power flow.

Motor Drives

Helps control heavy-duty motors in elevators, compressors, and conveyor belts.

UPS and Inverters

Ensures smooth energy conversion in backup systems and power inverters.
