2MBI200NC-12 Double IGBT Module – 200A 1200V

Introduction to 2MBI200NC-12 Double IGBT Module – 200A 1200V

The powerhouse behind any high-tech system of automation is the power electronics, and within this powerhouse is a vital component -The IGBT module. Could think of it as the bridge between control signals to high-power devices. It gives engineers a way to turn power on and off efficiently and safely. There are lots of other ones, but my personal favorite is the 2MBI200NC-12 Double IGBT Module because it’s both reliable and powerful.

Key Features of 2MBI200NC-12

• Rated Current : 200A (normal work, because the plate is relatively small area, if long work recommended not more than 60A, to enhance heat dissipation.).
• Rated Voltage : 1200V, designed for use in medium to high voltage applications.
• Dual IGBT : A pair of IGBT Transistors in a single package.
• Quick switching : low on-state and switching losses with high system efficiency.
• Low Vce : Reducing heat and saving energy.

Buy 2MBI200NC-12 Double IGBT Module – 200A 1200V online

If you’re interested in purchasing the 2MBI200NC-12 Double IGBT Module – 200A 1200V, you can easily buy it from our official website. We offer original, high-quality products with trusted customer support. Just click the link below to place your order now!

👉 click here

Overview of the 2MBI200NC-12

• 2MBI: Two modules in one package.
• 200: 200A of continuous current.
• NC: Fujitsu/Fuji series identifier.
• 12: 1200V voltage rating.

It’s a power-packed module built for serious industrial needs.

Technical Specifications

• Collector-Emitter Voltage (Vces): 1200V
• Collector Current (Ic): 200A
• Gate-Emitter Voltage (Vge): ±20V
• Power Dissipation (Pc): 780W
• Junction Temperature Range (Tj): -40°C to 150°C
• Isolation Voltage: 2500V (between terminals and base plate)
• Thermal Resistance: <0.25°C/W

These figures ensure that the module performs reliably under intense operating conditions.

Working Principle of IGBT Modules

Think of yourself as a water tap. Traditional switches are to old-school valves as vows of silence are to earplugs — you are either shutting them off entirely or opening them up all the way. IGBTs are a bit like smart faucets — you can just about dial in the flow.

In the present case, Insulated Gate Bipolar Transistors (IGBT) is as electronic valves. They turn on and off large currents according to gate signals. 2MBI200NC-12, having two IGBTs, can be efficiently used in more complicated switching functions.

Applications of 2MBI200NC-12

You’ll find this module powering critical systems such as:

• Industrial motor drives (AC/DC motor control)
• Uninterruptible Power Supplies (UPS)
• Solar and wind inverters
• Electric welding machines
• HVAC compressors
• Battery management systems

Basically, anywhere efficient and powerful switching is needed—this module shines.

Benefits in Real-World Use

Why do engineers love this module?

• Energy Efficiency: Lower conduction and switching losses.
• Heat Handling: Optimized for thermal performance.
• Compact Size: Saves space in tight industrial enclosures.
• Durability: Made to last, even under high stress.

Final Thoughts

The 2MBI200NC-12 Double IGBT Module is a stellar choice for anyone looking to power demanding applications with efficiency and reliability. With its balanced specs, durable design, and wide range of uses, it’s a module worth considering for engineers and innovators alike.
